Remote Wireless Hospital Room Pressure Monitoring

Monitor, log, and report room air pressure differential and air changes per hour. Schedule a convenient web demo today.



Product Finder
Request a Demo
differential-air-pressure-iconC

Room Air Pressure Monitoring

Hospital Rooms, Clean Rooms, Data Centers, etc.



Remote wireless technology and cloud-based software platform SoniCloud provide easy deployment and accurate, reliable pressure differential/air change per hour data for hospitals, healthcare, pharmacy, construction and commercial HVAC applications.

Features:

  • High-resolution differential air pressure monitoring with display for compounding rooms, isolation rooms, clean rooms, surgical suites and other pressure-sensitive environments, including non-critical care areas such as soiled linen closets, with resolution to plus or minus one percent of full-scale.
  • Construction applications include dust and airborne contaminant control between occupied and work areas.
  • Track and evaluate air velocity and flow to properly time air filter changes and predict overall efficiency of HVAC systems.

Detailed Reporting, Compliance & Efficiency

Sonicu differential air pressure monitoring delivers dependable cloud-based monitoring solutions for virtually any pressure differential application, including air changes per hour (ACH), for healthcare critical- and non-critical-care environments, pharmaceutical compounding, construction site containment and commercial HVAC monitoring and diagnostics.




Digital Meters and Sensors

ARC 440 Digital Meter - with Integrated Display

ARC-440-with-values-web

The ARC 440 is a plug 'n' play solution for Differential Air Pressure monitoring when a local display is desired. This four-port, digital meter with integrated local display screen provides local alarming and can simultaneously monitor room conditions including; differential air pressure, ambient temperature and humidity, door-closed, and air velocity (ACH) sensor.

Designed for hospital critical and non-critical care areas, pharmacy compounding rooms, research and life science as well as construction environments and commercial building automation applications.

Flexible, four-port digital meter accepts Sonicu's broad array of digital sensors that include:

  • Temperature
  • Temp & Humidity
  • Cryogenic
  • Ultra-Low Temp (ULT)
  • Air Pressure Differential

Onboard Li-ion rechargeable battery and SIM memory with DataSync feature provide a battery backup option and ensures data integrity in the event of a system interruption or power loss.

Multiple networking capabilities allow several units to be meshed into a unified system.






MVP 440 Digital Meter / 4-Port

MVP440-with-HMI-screen-3

A popular choice for hospital critical and non-critical care areas, pharmacy compounding rooms, research and life science as well as construction environments and commercial building automation applications. Optional flush-mount display is ideal for sterile environment applications.

Flexible, four-port digital meter accepts Sonicu's broad array of digital sensors that include:

  • Temperature
  • Temp & Humidity
  • Cryogenic
  • Ultra-Low Temp (ULT)
  • Air Pressure Differential

Can also configure for 4-20mA analog sensors, modbus, or dry-contact. RS485 port for modbus provides SMART IoT connectivity for monitoring virtually any device or variable.

Onboard Li-ion rechargeable battery and SIM memory with DataSync feature provide a battery backup option and ensures data integrity in the event of a system interruption or power loss.

Multiple networking capabilities allow several units to be meshed into a unified system.




MVP 410 Digital Meter - Single Port

mvp410-temperature-humidity-monitoring-meter

Flexible, single-port digital meter accepts Sonicu's broad array of digital sensors that include:

  • Temperature
  • Temp & Humidity
  • Cryogenic
  • Ultra-Low Temp (ULT)
  • Air Pressure Differential

Redundant power and on-board memory ensures data integrity in the event of a system interruption or power loss.

Onboard Li-ion rechargeable battery and SIM memory with DataSync feature provide a battery backup option and ensures data integrity in the event of a system interruption or power loss.

Multiple networking capabilities allow several units to be meshed into a unified system.




Digital Air Pressure Differential Sensor
Includes NIST Calibration Certificate

differential-air-pressure-sensor

Monitors air pressure between rooms to maintain safe environment. For healthcare, pharmaceutical, construction, and HVAC.

Simple plug-and-play deployment. Pickup options include air ducts, wall plate, and ceiling mount.

Range: +/- 4 inches water column
Accuracy: +/- .25%
Part No: 101275


The Sonicu Difference

  Advanced Alarming

Cloud-based software capabilities with predictive algorithms for tailored alarming to reduce alarm fatigue and spot trends.

  SMART Reporting

Automated logging and reporting unrivaled in the industry for effortless regulatory compliance.


   The Safest Network

Virtual Private Network (VPN) on Verizon's cellular platform that will eliminate security concerns when transmitting data to the cloud.

  Recalibration is Easy

All-digital temperature sensors for easy calibration renewal with Sonicu's SNAP calibration program.

      SMART Digital Sensors

SMART sensors with proprietary DataSync capture. Preserve and secure data in the event of transmission interruptions.

  Battery Backup

Industry-leading battery life on all sensors. In the event of a power outage Sonicu's wireless sensors continue to keep you notified.

   Flexible Transmission

Replace server-based systems and eliminate IT concerns with a variety of transmission signals including: 4G cellular, radio frequency, WiFi, and Ethernet.

    Ensuring Consistency

Service quality and connectivity reports provide detailed analysis of system operations.
